Cisco Isc Slot
Aggregate Throughput | 50 Mbps to 100 Mbps |
Total onboard WAN or LAN 10/100/1000 ports | 2 |
RJ-45-based ports | 2 |
SFP-based ports | 1 |
Enhanced service-module slots | 0 |
Doublewide service-module slots | 0 |
NIM slots | 2 |
OIR (all I/O modules) | Yes |
Onboard ISC slot | 1 |
Default memory double-data-rate 3 (DDR3) error-correction-code (ECC) DRAM (Combined control/services/data planes) | 4 GB |
Maximum memory DDR3 ECC DRAM (Combined control/services/data planes) | 8 GB |
Default memory DDR3 ECC DRAM (data plane) | NA |
Maximum memory DDR3 ECC DRAM (data plane) | NA |
Default memory DDR3 ECC DRAM (control/services plane) | NA |
Maximum memory DDR3 ECC DRAM (control/services plane) | NA |
Default flash memory | 4 GB |
Maximum flash memory | 8 GB |
External USB 2.0 slots (type A) | 1 |
USB console port -type B mini (up to 115.2 kbps) | 1 |
Serial console port – RJ45 (up to 115.2 kbps) | 1 |
Serial auxiliary port – RJ45 (up to 115.2 kbps) | 1 |
Power-supply options | External: AC and PoE |
Redundant power supply | N/A |
AC input voltage | 100 to 240 VAC autoranging |
AC input frequency | 47 to 63 Hz |
AC input current range, AC power supply (maximum) | 1.5 to 0.6A |
AC input surge current | 90 A peak and less than 3 Arms per half cycle |
Typical power (no modules) (watts) | 36 |
Maximum power with AC power supply (watts) | 125 |
Maximum power with PoE power supply (platform only) (watts) | 260 |
Maximum endpoint PoE power available from PoE power supply (watts) | 120 |
Cisco Isc Slot Machine
Cisco Integrated Services Router USB, Black (ISR4331/K9). Expansion slot type: Integrated Services Card (ISC), Network Interface Module (NIM), SFP, Number of total. Cisco Analog voice network interface card NIM-2FXS. Cisco Analog voice network interface card NIM-2FXS/4FXO. Cisco Fourth-Generation Multiflex Trunk Voice and WAN network interface module. SFPs for On-Board GE Ports. Cisco GLC-SX-MMD 1000BASE-SX SFP transceiver module, MMF, 850nm, DOM.
